Blackmagic Design Micro Converter SDI to HDMI 12G

Rp4,260,000.00

  • 1 x 12G-SDI Input, 1 x HDMI Output
  • 1 x 12G-SDI Loop Output
  • Selectable SD/HD Level A/B SDI Ports
  • Supports up to DCI 4K60 Resolution I/O
  • Automatic Input Signal Detection
  • Compact, Rugged Design
  • Embedded Audio, USB Type-C Power
  • A Power Supply Is Included
  • LED Video & Power Signal Indicators

Out of stock

Guaranteed safe checkout



Butuh Bantuan?  081217178890 | 081216422333
SKU: Blackmagic Design Micro Converter SDI to HDMI 12G Categories: , Product ID: 128444

Description

Description

Blackmagic Design Micro Converter SDI to HDMI 12G

Blackmagic Design Micro Converter SDI to HDMI 12G

Spesifikasi

Spesifikasi:

Inputs/Outputs
Video Inputs
1x BNC (12G-SDI) Female
Audio Inputs
No
Video Outputs
1x HDMI (2.0) Female 1x BNC (12G-SDI) Female (Loop Output)
Audio Outputs
No
Other I/O
1x USB-C Control, Firmware Input
Expansion Slots
No
Format Support
Input Video Format
SDI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K 24/25/29.97/30/47.95/48/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 480i / 525 lines 29.97 fps 576i / 625 lines 25 fps
Output Video Format
HDMI (8/10-Bit 4:2:2 RGB, YUV) DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps UHD 4K 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps DCI 2K 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps 1080PsF 25/29.97/30 fps 1080i 50/59.94/60 fps 720p 50/59.94/60 fps 480i / 525 lines 29.97 fps 576i / 625 lines 25 fps
Embedded Audio
HDMI/SDI
Standards
Video Standard Compliance
SMPTE 259M/292M/296M/424M/425M/ST-2081-1/ST-2081-10/ST-2082-1/ST-2082-10/ST-2084
HDCP Support
Yes: Version 2.2
HDR Support
Not Specified by Manufacturer
Hardware
OS Compatibility
macOS 10.15.15 or Later macOS 11.1 or Later Windows 10
Power
Power I/O
1x USB-C (4.4 to 5.2 VDC ) Input
Power Consumption
Device: 4 W
Environmental
Operating Temperature
32 to 72°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
0 to 90% ()
General
Dimensions
3.01 x 1.8 x 0.98" / 76.45 x 45.7 x 24.89 mm
Weight
5.29 oz / 150 g
Packaging Info
Package Weight
0.85 lb
Box Dimensions (LxWxH)
5.7 x 4 x 2.8"

Isi Dalam Box

Isi dalam box:

  • Blackmagic Design Micro Converter SDI to HDMI 12G
  • Power Supply
  • International Plug Se
