Blackmagic Design Mini Converter Analog to SDI 2

Rp 5.350.000

  • 1 x 12G-SDI Input, 1 x HDMI Output
  • 1 x 12G-SDI Loop Output
  • Selectable SD/HD Level A/B SDI Ports
  • Supports up to DCI 4K60 Resolution I/O
  • Automatic Input Signal Detection
  • Compact, Rugged Design
  • Embedded Audio, USB Type-C Power
  • A Power Supply Is Included
  • LED Video & Power Signal Indicators

Hubungi CS

Out of stock

Silahkan Klik jika ingin membeli via marketplace

Subsidi Ongkir untuk pembelian Minimal 500rb

  • Jaminan asuransi untuk kehilangan
  • Pengiriman 2×24 Jam
  • Order sebelum 14:00 WIB (Senin-Sabtu)
    untuk pengiriman hari yang sama.
Guaranteed Safe Checkout

Blackmagic Design Mini Converter Analog to SDI 2

Blackmagic Design Mini Converter Analog to SDI 2

Additional information

Weight 1 kg

Reviews

There are no reviews yet

Add a review
You must be logged in to post a review Log In

Spesifikasi:



Inputs/Outputs




























Video Inputs
1x BNC (12G-SDI) Female
Audio Inputs
No
Video Outputs
1x HDMI (2.0) Female
1x BNC (12G-SDI) Female (Loop Output)
Audio Outputs
No
Other I/O
1x USB-C Control, Firmware Input
Expansion Slots
No



Format Support
















Input Video Format
SDI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K 24/25/29.97/30/47.95/48/50/59.94/60 fps
1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
480i / 525 lines 29.97 fps
576i / 625 lines 25 fps
Output Video Format
HDMI (8/10-Bit 4:2:2 RGB, YUV)
DCI 4K at 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
UHD 4K 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
DCI 2K 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080p 23.98/24/25/29.97/30/47.95/48/50/59.94/60 fps
1080PsF 25/29.97/30 fps
1080i 50/59.94/60 fps
720p 50/59.94/60 fps
480i / 525 lines 29.97 fps
576i / 625 lines 25 fps
Embedded Audio
HDMI/SDI



Standards
















Video Standard Compliance
SMPTE 259M/292M/296M/424M/425M/ST-2081-1/ST-2081-10/ST-2082-1/ST-2082-10/ST-2084
HDCP Support
Yes: Version 2.2
HDR Support
Not Specified by Manufacturer



Hardware








OS Compatibility
macOS 10.15.15 or Later
macOS 11.1 or Later
Windows 10



Power












Power I/O
1x USB-C (4.4 to 5.2 VDC ) Input
Power Consumption
Device: 4 W



Environmental
















Operating Temperature
32 to 72°F / 0 to 40°C
Storage Temperature
-4 to 140°F / -20 to 60°C
Operating Humidity
0 to 90% ()



General












Dimensions
3.01 x 1.8 x 0.98" / 76.45 x 45.7 x 24.89 mm
Weight
5.29 oz / 150 g



Packaging Info












Package Weight
0.85 lb
Box Dimensions (LxWxH)
5.7 x 4 x 2.8"

Isi dalam box:



  • Blackmagic Design Micro Converter SDI to HDMI 12G

  • Power Supply

  • International Plug Se
