Sony Camcorder PXW-Z90
Sony Camcorder PXW-Z90 adalah camcorder dari Sony menawarkan kualitas siaran 4K dengan fitur-fitur canggih seperti fokus otomatis berkecepatan tinggi, alur kerja HDR Instan, hingga 960fps* super slow-motion dan streaming pada 2.4GHz atau 5GHz** dengan QoS.
*960 fps (NTSC). 1000 fps (PAL).
**5GHz support tergantung pada peraturan masing-masing negara/regional.
Camcorder Sony Z90 menggabungkan sistem Fast Hybrid AF yang canggih, di samping pendeteksian wajah dan teknologi fokus otomatis lock-on, membuatnya mudah untuk fokus dan melacak subjek saat syuting.
Sony Camcorder PXW-Z90 adalah camcorder profesional palm-sized pertama yang menghadirkan konten 4K High Dynamic Range (HDR) yang memukau dengan alur kerja berbasis file Hybrid Log-Gamma (HLG). S-Log3 juga didukung, memungkinkan Anda untuk membuat citra indah dengan rentang warna yang lebar.
Camcorder Sony Z90 memberikan 120 frame per detik (fps) yang menakjubkan dalam Full HD XAVC 10bit 4:2:2, memberikan Anda lima kali ekspresi gerak lambat. Frame rate yang lebih tinggi hingga 960fps menggunakan S&Q motion cache recording juga dimungkinkan untuk fleksibilitas kreatif yang lebih baik.
Camcorder ini memiliki standar siaran output 3G-SDI (mendukung 1080 60p / 50p), sebuah Multi-Interface (MI) Shoe, HDMI dan remote interface untuk terhubung dan mengendalikan secara remote berbagai macam aksesoris Sony yang kompatibel, termasuk membuat simple live solution ketika terhubung ke MCX-500 multi camera live producer opsional dan RM-30BP Remote Commander.
Untuk memberikan kinerja pencitraan yang tinggi, sensor gambar CMOS bertenaga tinggi yang berukuran 14.2 megapiksel 1.0-type memberikan efek defocus bokeh latar belakang yang indah dan sensitivitas superior untuk menangkap gambar berkualitas tinggi dengan lebih sedikit noise, bahkan di bawah gelap atau kondisi terang. Sensor ini memadukan hingga 273 titik AF phase-detection yang secara padat menutup sekitar 84% dari area gambar, untuk pelacakan subjek yang tepat di seluruh frame pemotretan.
Camcorder Sony Z90 dilengkapi dengan lensa wide angle ZEISS Vario-Sonnar T 29mm, ideal untuk menangkap lanskap panorama. Zoom optik 12x dapat ditingkatkan menjadi 18x dengan Clear Image Zoom, mempertahankan resolusi QFHD menggunakan Teknologi Resolusi Super atau 24x dalam HD. Selain itu, extender digital dapat menggandakan rentang ini hingga zoom 48x.
Fitur Utama Sony Camcorder PXW-Z90
- Pencitraan revolusioner dengan Exmor RS
- Fokus otomatis Fast Hybrid
- Alur kerja Instant HDR
- Slow Motion yang menakjubkan dalam Full HD
- Kualitas siaran 4K (QFHD) dan HD
- Jaringan untuk mobilitas tinggi
- Lensa wide angle zoom dengan kontrol yang bagus
- Kualitas monitoring yang luar biasa viewfinder OLED
- Dual XLR input
- Remote operation
- Dual media slots
- Multi-Interface (MI) Shoe
- Berbagai pilihan koneksi
- Simple live solution
- Sinkronisasi beberapa camcorder dengan mudah
Ulasan Video Camcorder Sony Z90
Spesifikasi Sony Camcorder PXW-Z90
General
| Mass | Approx 1020g (with lens hood, eyecup) |
| Approx. 2 lb 4.0 oz (with lens hood,eyecup) | |
| Approx. 1390g (with lens hood, handle, eyecup, NP-FV70A battery) | |
| Approx. 3lb 1oz (with lens hood, handle, eyecup, NP-FV70A battery) | |
| Dimensions (W x H x D) | 121.0mm×104.0mm×274.5mm (With the accessories (lens hood, large eyecup) ,excluding the grip belt and including the projecting parts) |
| 4 7/8 x 4 1/8 x 10 7/8 inches (With the accessories (lens hood, large eyecup) ,excluding the grip belt and including the projecting parts) | |
| 130.0 x 181.5 x 287.0 mm (With the accessories (lens hood, large eyecup, XLR handle unit) , excluding the grip belt and including the projecting parts) | |
| 5 1/8 x 7 1/4 x 11 3/8 inches (With the accessories (lens hood, large eyecup, XLR handle unit) , excluding the grip belt and including the projecting parts) | |
| Power Requirements | DC In: 8.4V |
| Battery: 7.4V | |
| Power Consumption | Approx. 6.5 W(while recording with viewfinder and XAVC QFHD 2160/30p 60Mbps) |
| Approx. 6.9 W (while recording with LCD and XAVC QFHD 2160/30p 60Mbps) | |
| Operating Temperature | 0°C to 40°C |
| 32°F to 104°F | |
| Storage Temperature | -20°C to +60°C |
| -4°F to +140°F | |
| Battery Operating Time | Approx. 140min. with NP-FV70A battery (while recording with LCD, XAVC QFHD 2160/30p, 60Mbps) |
| Approx. 265 min. with NP-FV70A battery (while playing with LCD, XAVC QFHD 2160/30p, 60Mbps) | |
| Recording Format (Video) | XAVC QFHD : MPEG-4 AVC/H.264 4:2:0 Long profile |
| XAVC HD : MPEG-4 AVC/H.264 4:2:2 Long profile | |
| XAVC Proxy : MPEG-4 AVC/H.264 4:2:0 Long profile | |
| MPEG HD422 (CBKZ-SLMP required) : MPEG-2 422P@HL 4:2:2 Long profile | |
| MPEG HD420 (CBKZ-SLMP required) : MPEG-2 MP@HL 4:2:0 Long profile | |
| MPEG HD Proxy (CBKZ-SLMP required) : MPEG-4 AVC/H.264 4:2:0 Long profile | |
| AVCHD : MPEG-4 AVC/H.264 AVCHD 2.0 format compatible | |
| Recording Format (Audio) | XAVC QFHD : Linear PCM 2ch, 24bit, 48kHz |
| XAVC HD : Linear PCM 2ch, 24bit, 48kHz | |
| XAVC Proxy : AAC-LC 2ch、16bit、48kHz | |
| MPEG HD422 (CBKZ-SLMP required) : Linear PCM 2ch, 24bit, 48kHz | |
| MPEG HD420 (CBKZ-SLMP required) : Linear PCM 2ch, 16bit, 48kHz | |
| MPEG HD Proxy (CBKZ-SLMP required) : AAC-LC 2ch、16bit、48kHz | |
| AVCHD : Linear PCM 2ch, 16bit, 48kHz / Dolby Digital 2ch, 16bit, 48kHz | |
| Recording Frame Rate | XAVC QFHD (3840 x 2160) @29.97p, 25p, 23.98p 100Mbps/60Mbps |
| XAVC HD (1920 x 1080) @59.94p, 50p, 29.97p, 25p, 23.98p, 50Mbps/35Mbps | |
| XAVC HD (1920 x 1080) @59.94i, 50i, 50Mbps/35Mbps/25Mbps | |
| XAVC HD (1280 x 720) @59.94p, 50p, 50Mbps | |
| XAVC Proxy (1280 x 720) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps | |
| XAVC Proxy (640 x 360) @59.94p, 50p, 29.97p, 25p, 23.98p, 3Mbps | |
| MPEG HD422 (1920 x 1080) (CBKZ-SLMP required) @59.94i, 50i, 29.97p, 25p, 23.98p, 50Mbps | |
| MPEG HD422 (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, 50Mbps | |
| MPEG HD420 (1920 x 1080) @59.94i, 50i, 29.97p, 25p, 23.98p, HQ mode(35Mbps) | |
| MPEG HD420 (1440 x 1080) (CBKZ-SLMP required) @59.94i, 50i, HQ mode(35Mbps) | |
| Recording Frame Rate (Cont.) | MPEG HD420 (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, HQ mode(35Mbps) |
| MPEG HD Proxy (1280 x 720) (CBKZ-SLMP required) @59.94p, 50p, 29.97p, 25p, 23.98p, 9Mbps | |
| MPEG HD Proxy (640 x 360) (CBKZ-SLMP required) @59.94p, 50p, 29.97p, 25p, 23.98p 3Mbps | |
| AVCHD (1920 x 1080)@59.94p, 50p, PS mode (28Mbps) | |
| AVCHD (1920 x 1080) @59.94i/50i FX mode (24Mbps) FH mode(17Mbps) | |
| AVCHD (1920 x 1080) @29.97p/25p/23.98p, FX mode (24Mbps) | |
| AVCHD (1440 x 1080)@59.94i, 50i LP mode (5Mbps) | |
| AVCHD (1280 x 720)@59.94p, 50p, HQ mode (9Mbps) | |
| Recording/Playback Time | XAVC QFHD @LPCM 2ch 100 Mbps |
| Approx. 65 min with 64 GB memory card | |
| XAVC QFHD @LPCM 2ch 60 Mbps | |
| Approx. 100 min with 64 GB memory card | |
| XAVC HD @LPCM 2ch 50 Mbps | |
| Approx. 120 min with 64 GB memory card | |
| XAVC HD @LPCM 2ch 35 Mbps | |
| Approx. 170 min with 64 GB memory card | |
| XAVC HD @LPCM 2ch 25 Mbps | |
| Approx. 220 min with 64 GB memory card | |
| MPEG HD422 (CBKZ-SLMP required) @LPCM 2ch 50 Mbps | |
| Approx. 110 min with 64 GB memory card | |
| MPEG HD420 (CBKZ-SLMP required) @LPCM 2ch HQ Mode | |
| Approx. 170 min with 64 GB memory card | |
| AVCHD @LPCM 2ch PS Mode | |
| Approx. 305 min with 64 GB memory card | |
| AVCHD @LPCM 2ch FX Mode | |
| Approx. 360 min with 64 GB memory card | |
| Recording/Playback Time (cont.) | AVCHD @LPCM 2ch FH Mode |
| Approx. 495 min with 64 GB memory card | |
| AVCHD @LPCM 2ch HQ Mode | |
| Approx. 880 min with 64 GB memory card | |
| AVCHD @LPCM 2ch LP Mode | |
| Approx. 1540 min with 64 GB memory card |
Lensa
| Lens Mount | Fixed |
| Zoom Ratio | 12x (optical), servo |
| Focal Length | f=9.3 – 111.6mm |
| equivalent to f=29.0 – 348.0mm on 35 mm lens(16:9) | |
| equivalent to f=32.8 – 393.6mm on 35mm lens(3:2) | |
| Iris | F2.8 – F4.5 |
| auto/manual selectable | |
| Focus | AF/MF selectable |
| 10 mm to ∞ (Wide) | |
| 1000 mm to ∞ (Tele) | |
| Image Stabilizer | ON/OFF selectable, shift lens |
| Filter Diameter | M62 mm |
Camera Section
| Imaging Device (Type) | 1.0-type (13.2mm x 8.8mm) back-illuminated Exmor RS CMOS sensor |
| Effective Picture Elements | Approx.14.2M pixels(16:9)/Approx.12.0M pixels(3:2) |
| Built-in Optical Filters | OFF: Clear, 1: 1/4ND, 2: 1/16ND, 3: 1/64ND |
| Minimum Illumination | Standard [60i] 3lux(1/60 Shutter Speed, gain 33dB) |
| Standard [50i] 3lux(1/50 Shutter Speed, gain 33dB) | |
| LowLux [60i] 1.7lux(1/30 Shutter Speed, gain 33dB) | |
| LowLux [50i] 1.7lux(1/25 Shutter Speed, gain 33dB) | |
| Shutter Speed | [60i]: 1/8 – 1/10,000 |
| (1/6 – 1/10,000 when shooting with 24p) | |
| [50i]: 1/6 -1/10,000 | |
| Slow & Quick Motion Function | [60i]:2160p:Frame rate selectable 1,2,4,8,15,30fps |
| [50i]:2160p:Frame rate selectable 1,2,3,6,12,25fps | |
| [60i]:1080p:Frame rate selectable 1,2,4,8,15,30,60,120fps | |
| [50i]:1080p:Frame rate selectable 1,2,3,6,12,25,50,100fps | |
| Super Slow Motion | [60i]1080p:Frame rate selectable 240,480,960fps |
| [50i]:1080p:Frame rate selectable 250,500,1000fps | |
| White Balance | Preset（Indoor:3200K, Outdoor:5600K±7 steps, Color temparature set range:2300-15000K) |
| Onepush A, B, Auto selectable | |
| Gain | -3, 0, 3, 6, 9, 12,15, 18, 21, 24, 27, 30, 33 dB, AGC |
| Gamma Curve | Selectable |
Input/Output
| Audio Input | XLR-type 3-pin (female) (x2), line/mic/mic +48 V selectable |
| Video Output | Integrated into Multi/Micro USB jack（×1）, Composite 1.0Vp-p, 75Ω |
| Audio Output | Integrated into Multi/Micro USB jack |
| SDI Output | BNC (x1), 3G/HD/SD |
| SMPTE 424M/292M/259M standards | |
| USB | Multi/Micro USB jack (x1) |
| Headphone Output | Stereo mini jack (x1) |
| Speaker Output | Monaural |
| DC Input | DC jack |
| Remote | Integrated into Multi/Micro USB jack |
| Stereo mini-mini jack (Φ2.5mm) | |
| HDMI Output | Type A (x1) |
Monitoring
| Viewfinder | 1.0cm（0.39 type）OLED |
| Approx. 2.36M dots | |
| LCD | 8.8cm（3.5 type) |
| Approx. 1.56M dots |
Built-in Microphone
| Built-in Microphone | Omni-directional stereo electret condenser microphone |
Media
| Type | Memory Stick Pro Duo™ and SD/SDHC/SDXC compatible x1 SD/SDHC/SDXC x1 |
Wi-Fi/NFC
| Supported format | IEEE 802.11 a/b/g/n/ac |
| Frequency band | 2.4 GHz bandwidth |
| 5.2/5.3/5.6/5.8 GHz bandwidth | |
| Security | WEP/WPA-PSK/WPA2-PSK |
| NFC | NFC Forum Type 3 Tag compliant |
