Type |
Digital single-lens non-reflex AF / AE camera |
Recording Media |
SD memory card, SDHC memory card, SDXC memory card
* Compatible with UHS-I |
Image Sensor Size |
Approx. 22.3 x 14.9mm |
Compatible Lenses |
(1) Canon EF-M lenses |
(2) Canon EF lenses (including EF-S lenses) *
* With Mount Adapter EF-EOS M.
(35 mm-equivalent focal length is approx. 1.6 times the lens focal length) |
Lens Mount |
Canon EF-M mount |
|
|
Type |
CMOS sensor |
Effective Pixels |
Approx. 24.2 megapixels |
Aspect Ratio |
3:2 |
Dust Delete Feature |
Auto, Manual, Dust Delete Data appending |
|
|
Recording format |
Design rule for Camera File System (DCF) 2.0 |
Image type |
JPEG, RAW (14-bit Canon original)
RAW + JPEG simultaneous recording possible |
Recording pixels |
L (Large): |
Approx. 24.00 megapixels (6000 x 4000) |
M (Medium): |
Approx. 12.40 megapixels (4320 x 2880) |
S1 (Small 1): |
Approx. 5.50 megapixels (2880 x 1920) |
S2 (Small 2): |
Approx. 3.50 megapixels (2304 x 1536) |
S3 (Small 3): |
Approx. 350,000 pixels (720 x 480) |
RAW: |
Approx. 24.00 megapixels (6000 x 4000) |
|
|
Type |
Hybrid CMOS AF III (1-point AF, face + tracking priority AF) |
AF Points |
49 points (Maximum) |
Focusing Brightness Range |
EV 2 - 18 (at room temperature, ISO 100) |
AF Operation |
One-Shot AF, Servo AF |
Continuous AF |
Possible |
AF-assist beam |
Built-in (LED lamp) |
|
|
Type |
Electronically-controlled, focal-plane shutter |
Shutter Speeds |
1/4000 sec. to 30 sec. (Total shutter speed range; available range varies by shooting mode.), Bulb
X-sync at 1/200 sec. |
|
|
Built-in Flash |
Retracting, manual pop-up flash
Guide number approx. 5 (ISO 100/m)
Supports angle of view equivalent to focal length of approx. 18mm (35mm-equivalent: approx. 29mm)
Recharging time approx. 3sec. |
External Flash |
EX-series Speedlites (Flash functions settable with the camera) |
Flash Metering |
E-TTL II autoflash |
Flash exposure compensation |
±2 stops in 1/3-stop increments |
FE LOCK |
Provided |
|
|
Drive modes |
Single shooting, continuous shooting |
Self-timer mode |
Off/ 2-second self-timer/ 10-second self-timer/ Remote control |
Continuous shooting speed |
Max. approx. 4.2 shots/sec. |
Max. burst |
JPEG Large / Fine: |
Approx. 1000 shots |
RAW: |
Approx. 5 shots |
RAW + JPEG Large / Fine |
Approx. 4 shots |
* Figures are based on Canon’s testing standards (ISO 100 and “Standard” Picture Style) using a 16 GB UHS-I memory card, which complies with Canon testing standards. |
Movie Compression |
MPEG-4 AVC/H.264
Variable (average) bit rate |
Audio Recording Format |
MPEG-4 AAC-LC |
Recording Format |
MP4 |
Recording Size
and Frame Rate |
1920 x 1080 (Full HD) |
30p / 25p / 24p |
1280 x 720 (HD) |
60p / 50p |
640 x 480 (SD) |
30p / 25p |
* 30p: 29.97 fps, 25p: 25.00 fps, 24p: 23.976 fps, 60p: 59.94 fps, 50p: 50.00 fps |
File size |
1920x1080 (30p / 25p / 24p) |
Approx. 172.6MB/min. |
1280x720 (60p / 50p) |
Approx. 115.4MB/min. |
640x480 (30p / 25p) |
Approx. 22.4MB/min. |
Focusing |
Hybrid CMOS AF III method* (1-point AF, Face + Tracking priority AF) Manual focus
* Focusing brightness range: EV 2 - 18 (at room temperature, ISO 100) |
Metering modes |
Evaluative |
Servo AF |
Provided |
Metering Range |
EV 1 - 20 (at room temperate, ISO 100) |
Exposure control |
Program AE for movies and manual exposure |
Exposure compensation |
±3 stops in 1/3-stop increments. |
ISO speed
(Recommended exposure index) |
With automatic exposure: |
ISO 100 – 3200 (Full HD)
ISO 100 – 6400 (HD/SD) set automatically |
With manual exposure: |
ISO 100 - 3200 (Full HD) / ISO 100-6400 (HD / SD) set automatically / manually, H (ISO 6400 (Full HD) / ISO 12800 (HD / SD) equivalent) speed possible |
Miniature effect movie |
Provided |
Sound recording |
Built-in stereo microphone
External stereo microphone terminal provided
Audio recording level adjustable, wind filter(for built-in microphone) provided, attenuator provided |
Grid Display |
Two types |
|
|
Type |
TFT colour liquid-crystal monitor |
Monitor Size and Dots |
Wide, 7.7 cm (3.0-in.) (3:2) with approx. 1.04 million dots |
Angle adjustment |
Possible |
Brightness adjustment |
Manual (5 levels) |
Interface languages |
25 |
Touch screen technology |
Capacitive sensing |
Feature guide |
Displayable |
|
|
Digital terminal |
PC networking for direct print (Hi-Speed USB equivalent) |
HDMI Mini OUT Terminal |
Type C (auto switching of resolution) |
External microphone IN terminal |
3.5mm diameter stereo mini jack |
Wireless Remote Control |
Remote Controller RC-6 |
|
|
Standard compliance |
IEEE 802.11 b/g/n |
Transmission Methods |
DS-SS modulation (IEEE 802.11b) OFDM modulation (IEEE 802.11 g/n) |
Transmission range |
Approx. 15m (49.21ft.)
*When connected to a smartphone
*With no obstructions between the transmitting and receiving antennas and no radio interference |
Transmission frequency (central frequency) |
Frequency: 2412 to 2462 MHz
Channels: 1 to 11 ch |
Connection method |
Infrastructure mode*, camera access point mode, ad hoc mode
*Wi-Fi Protected Setup supported |
Security |
Authentication method: Open system, Shared key, WPA-PSK, WPA2-PSK
Encryption: WEP, TKIP, AES |
|
|
Battery |
Battery Pack LP-E17 (Quantity 1)
* AC power can be supplied via AC Adapter Kit ACK-E17 |
Battery Life (Based on CIPA testing standards) |
Approx. 250 shots at 23°C / 73°F, approx. 185 shots at 0°C / 32°F |
Movie shooting time |
Approx. 1 hr. 40 min. at 23°C / 73°F
Approx. 1 hr. 35 min. at 0°C / 32°F
(with a fully-charged Battery Pack LP-E17) |
|
|
Dimensions (W x H x D) |
Approx. 110.9 x 68.0 x 44.4mm / 4.4 x 2.7 x 1.7in. |
Weight |
Approx. 366g / 12.9oz. (CIPA Guidelines : Body + Battery Pack + Card),
Approx. 319g / 11.3oz. (Body only, excluding lens cap) |
|
|
Working temperature range |
0°C - 40°C / 32°F - 104°F |
Working humidity |
85% or less |
Battery Pack LP-E17 |
|
Type |
Rechargeable lithium-ion battery |
Rated voltage |
7.2 V DC |
Battery capacity |
1040 mAh |
Working temperature range |
During charging: 5°C - 40°C / 41°F - 104°F
During shooting: 0°C - 40°C / 32°F - 104°F |
Working humidity |
85% or less |
Dimensions (W x H x D) |
Approx. 33.0 x 14.0 x 49.4mm / 1.3 x 0.55 x 1.94in. |
Weight |
Approx. 45g / 1.59oz. |
Battery Charger LC-E17 |
|
Compatible battery |
Battery Pack LP-E17 |
Recharging time |
Approx. 2 hours (at room temperature) |
Rated input |
100 - 240 V AC (50 / 60 Hz) |
Rated output |
8.4 V DC / 700 mA |
Working temperature range |
5°C - 40°C / 41°F - 104°F |
Working humidity |
85% or less |
Dimensions (W x H x D) |
Approx. 67.3 x 27.7 x 92.2mm / 2.65 x 1.09 x 3.63in |
Weight |
Approx. 85g / 3.0oz. |
