Type |
Digital, single-lens reflex, AF/AE camera with built-in flash |
Recording media |
SD/SDHC*/SDXC* memory cards
* UHS-I cards supported |
Image sensor size |
Approx. 22.3 x 14.9mm |
Compatible lenses |
Canon EF lenses (including EF-S lenses)
* Excluding EF-M lenses(35mm-equivalent angle of view is that of a lens with approx. 1.6x the focal length indicated.) |
Lens mount |
Canon EF mount |
Image Sensor |
|
Type |
CMOS sensor |
Effective pixels |
Approx. 24.2 megapixels
* Rounded off to the nearest 10,000th |
Aspect ratio |
3:2 |
Dust delete feature |
Auto, Manual, Dust Delete Data appending |
Recording System |
|
Recording format |
Design rule for Camera File System (DCF) 2.0 |
Image type |
JPEG, RAW (14-bit Canon original), RAW+JPEG simultaneous recording possible |
Pixels recorded |
L (Large) |
24.0 megapixels (6000 x 4000) |
M (Medium): |
Approx. 10.6 megapixels (3984 x 2656) |
S1 (Small 1): |
Approx. 5.9 megapixels (2976 x 1984) |
S2 (Small 2): |
Approx. 2.5 megapixels (1920 x 1280) |
S3 (Small 3): |
Approx. 350,000 pixels (720 x 480) |
RAW: |
24.0 megapixels (6000 x 4000) |
M-RAW: |
13.5 megapixels (4500 x 3000) |
S-RAW: |
6.0 megapixels (3000 x 2000) |
Aspect ratio |
3:2, 4:3, 16:9, 1:1 |
Create / select a folder |
Possible |
File numbering |
Continuous, Auto reset, Manual reset |
Image Processing During Shooting |
Picture Style |
Auto, Standard, Portrait, Landscape, Fine Detail, Neutral,Faithful, Monochrome, User Defined 1 - 3 |
White balance |
Auto (Ambience priority), Auto (White priority), Preset (Daylight, Shade, Cloudy, Tungsten light, White fluorescent light, Flash), Custom, Color temperature setting (approx. 2500 - 10000K), White balance correction, and White balance bracketing provided
* Flash color temperature information transmission enabled |
Noise reduction |
Applicable to long exposures and high ISO speed shots |
Automatic image brightness correction |
Auto Lighting Optimizer provided |
Highlight tone priority |
Provided |
Lens aberration correction |
Peripheral illumination correction, Chromatic aberration correction, Distortion correction |
Viewfinder |
|
Type |
Eye-level pentaprism |
Coverage (by aspect ratio) |
3:2 (vertical: approx. 100%, horizontal: approx. 100%), |
4:3 (vertical: approx. 100%, horizontal: approx. 97%), |
16:9 (vertical: approx. 97%, horizontal: approx. 100%), |
1:1 (vertical: approx. 100%, horizontal: approx. 96%) |
*With eyepoint at approx. 22mm. |
Magnification |
Approx. 0.95x (-1m-1 with 50mm lens at infinity) |
Eye point |
Approx. 22mm (from eyepiece lens center at -1m-1) |
Diopric adjustment range |
Approx. -3.0 - +1.0m-1 (dpt) |
Focusing screen |
Fixed |
Grid display |
Provided |
Electronic level |
Provided |
Mirror |
Quick-return type |
Depth-of-field preview |
Provided |
Autofocus (for viewfinder shooting) |
Type |
TTL secondary image-registration, phase-difference detection with the dedicated AF sensor |
AF points |
45 (Cross-type AF point Max. 45 points)
* Number of available AF points, Dual cross-type AFpoints, and cross-type AF points vary depending on the lens used and aspect ratio settings.
* Dual cross-type focusing at f/2.8 with center AF point.(AF group: When Group A lenses are used) |
Focusing brightness range |
EV -3 - 18 (with the center AF point supporting f/2.8, One-Shot AF, at room temperature, ISO 100) |
Focus operation |
One-Shot AF, AI Servo AF, AI Focus AF, Manual focusing (MF) |
AF area selection mode |
Single-point AF (Manual selection), Zone AF (Manual selection of zone), Large Zone AF (manual selection of zone), 45-point automatic selection AF |
AF point automatic selection conditions |
AF points can be selected automatically using information on colors equivalent to skin tones |
AI Servo AF characteristics |
Tracking sensitivity, Acceleration / deceleration tracking, AF point auto switching |
AF fine adjustment |
AF Microadjustment (All lenses by same amount or Adjust by lens) |
AF-assist beam |
Small series of flashes fired by built-in flash |
Exposure Control |
|
Metering mode |
63-zone TTL open-aperture metering using 7560-pixel RGB plus IR metering sensor
- Evaluative metering (linked to all AF points)
- Partial metering (approx. 6.0% of viewfinder at center)
- Spot metering (approx. 3.8% of viewfinder at center)
- Center-weighted average metering
|
Metering brightness range |
EV 1 - 20 (at room temperature, ISO 100) |
Shooting mode |
Basic Zone modes |
Scene Intelligent Auto, Flash Off, Creative Auto, Special scene modes (Food, Kids, Candlelight, Night Portrait, Handheld Night Scene, HDR Backlight Control, Portrait, Landscape, Close-up, Sports), Creative filters (Grainy B/W, Soft focus, Fish-eye effect, Toy camera effect,Miniature effect, Water painting effect, HDR art standard,HDR art vivid, HDR art bold, HDR art embossed) |
Creative Zone modes: |
Program AE, Shutter-priority AE, Aperture-priority AE,Manual exposure, Bulb exposure, Custom shootingmode |
ISO speed (Recommended exposure index) |
Basic Zone modes*: |
ISO 100 - ISO 6400 set automatically |
* Handheld Night Scene: |
ISO 100 - ISO 12800 set automatically, Landscape: ISO 100 - ISO 1600 set automatically |
P, Tv, Av, M, B: ISO Auto, ISO 100 - ISO 16000 set manually (1/3- and whole-stop increments), and ISO expansion to H (equivalent to ISO 25600) |
ISO speed settings |
Range for stills, Auto range, and Minimum shutter speed for auto settable |
Exposure compensation |
Manual: |
±5 stops in 1/3- or 1/2-stop increments |
AEB: |
±3 stops in 1/3- or 1/2-stop increments (can be combined with manual exposure compensation) |
AE lock |
Auto: |
Applied in One-Shot AF with evaluative metering when focus is achieved |
Manual: |
With AE lock button |
Anti-flicker |
Possible |
Interval timer |
Shooting interval and shot count settable |
Bulb timer |
Bulb exposure time settable |
HDR Shooting |
|
Dynamic range adjustment |
Auto, ±1, ±2, ±3 |
Effects |
Natural, Art standard, Art vivid, Art bold, Art embossed |
Auto image alignment |
Provided |
Multiple Exposures |
|
Number of multiple exposures |
2 - 9 exposures |
|
Multiple-exposure control |
Additive, Average |
Shutter |
|
Type |
Electronically-controlled, focal-plane shutter |
Shutter speed |
1/8000sec. to 30sec. (total shutter speed range; available range varies by shooting mode), Bulb, X-sync at 1/250sec. |
Drive System |
|
Drive mode |
Single shooting, High-speed continuous shooting, Low-speed continuous shooting, Silent single shooting, Silent continuous shooting, 10-sec. self-timer/remote control, 2-sec. self-timer/remote control |
Continuous shootingspeed |
High-speed continuous shooting: |
Max. approx. 7.0 shots/sec.*
* Max. approx. 5.0 shots/sec. during Live View shooting or when [Servo AF] is set. |
Low-speed continuous shooting: |
Max. approx. 3.0 shots/sec. |
Silent continuous shooting: |
Max. approx. 3.0 shots/sec. |
Max. burst |
JPEG Large/Fine: |
Approx. 77 shots (approx. 110 shots) |
RAW: |
Approx. 20 shots (approx. 25 shots) |
RAW+JPEG Large/Fine: |
Approx. 20 shots (approx. 22 shots) |
* Figures are based on Canon’s testing standards (3:2 aspect ratio, ISO 100 and Standard Picture Style) using an 8GB card. |
* Figures in parentheses apply to an UHS-I compatible 16GB card based on Canon’s testing standards. |
Flash |
|
Built-in flash |
Retractable, auto pop-up flash
Guide No.: Approx. 12 / 39.4 (ISO 100, in meters / feet)
Flash coverage: Approx. 17mm lens angle of view
Recharge time: Approx. 3sec. |
External Speedlite |
Compatible with EX-series Speedlites |
Flash metering |
E-TTL II autoflash |
Flash exposure compensation |
±3 stops in 1/3- or 1/2-stop increments |
FE lock |
Provided |
PC terminal |
None |
Flash control |
Built-in flash function settings, external Speedlite function settings, external Speedlite Custom Function settings Wireless flash control via optical transmission possible |
Live View Shooting |
|
Focus method |
Dual Pixel CMOS AF system |
AF method |
Face+Tracking, FlexiZone-Multi, FlexiZone-Single Manual focus (approx. 5x / 10x magnification possible) |
AF operation |
One-Shot AF, Servo AF |
Focusing brightness range |
EV 0 - 18 (at room temperature, ISO 100) |
Metering mode |
Evaluative metering (315 zones), Partial metering (approx. 6.1% of Live View screen), Spot metering (approx. 2.6% of Live View screen), Center-weighted average metering |
Metering brightness range |
EV 0 - 20 (at room temperature, ISO 100) |
Exposure compensation |
±3 stops in 1/3-stop or 1/2-stop increments |
Creative filters |
Provided |
Silent LV shooting |
Provided (Mode 1 and 2) |
Touch shutter |
Provided |
Grid display |
Three types |
Movie Shooting |
|
Recording format |
MOV/MP4 |
Movie |
MPEG-4 AVC / H.264 Variable (average) bit rate |
Audio |
MOV: Linear PCM, MP4: AAC |
Recording size and frame rate |
[MOV] |
Full HD (1920x1080): |
29.97p / 25.00p / 23.98p |
[MP4] |
Full HD (1920x1080): |
59.94p / 50.00p / 29.97p / 25.00p / 23.98p |
HD (1280x720): |
59.94p / 50.00p / 29.97p / 25.00p |
Compression method |
[MOV] : |
ALL-I (For editing / I-only) |
[MP4] : |
IPB (Standard), IPB (Light) |
Bit rate |
[MOV] |
Full HD (29.97p / 25.00p / 23.98p) / ALL-I: |
Approx. 90Mbps |
[MP4] |
Full HD (59.94p / 50.00p) / IPB (Standard) : |
Approx. 60Mbps |
Full HD (29.97p / 25.00p / 23.98p) / IPB (Standard) : |
Approx. 30Mbps |
Full HD (29.97p / 25.00p) / IPB (Light) : |
Approx. 12Mbps |
HD (59.94p / 50.00p) / IPB (Standard) : |
Approx. 26Mbps |
HD (29.97p / 25.00p) / IPB (Light) : |
Approx. 4Mbps |
HDR Movie Shooting : |
Approx. 30Mbps |
Focus method |
Dual Pixel CMOS AF system |
AF method |
Face+Tracking, FlexiZone-Multi, FlexiZone-Single Manual focus (approx. 5x / 10x magnification possible) |
Movie Servo AF |
Provided
* Movie Servo AF customizable |
Digital zoom |
Approx. 3 - 10x |
Focusing brightness range |
EV 0 - 18 (at room temperature, ISO 100) |
Metering mode |
Center-weighted average or Evaluative metering |
Metering brightness range |
EV 0 - 20 (at room temperature, ISO 100) |
Exposure control |
Autoexposure shooting (Program AE for movie shooting) and manual exposure |
Exposure compensation |
±3 stops in 1/3- or 1/2-stop increments |
ISO speed (Recommended exposure index) |
For autoexposure shooting: |
ISO 100 - ISO 12800 set automatically. In Creative Zone modes, the upper limit is expandable to H (equivalent to ISO 25600). |
For manual exposure shooting: |
ISO Auto (ISO 100 - ISO12800 set automatically), ISO 100 - ISO 12800 set manually (1/3- and whole-stop increments), expandableto H (equivalent to ISO 25600) |
ISO speed settings |
Range for movie shooting settable |
HDR Movie Shooting |
Possible |
Creative filters for movies |
Memory, Dream, Old Movies, Dramatic B&W, Miniature effect movie |
Video snapshots |
Settable to 2sec. / 4sec. / 8sec. |
Sound recording |
Built-in stereo microphones, external stereo microphone terminal provided
Sound-recording level adjustable, wind filter provided, attenuator provided |
Headphones |
Headphone terminal provided, sound volume adjustable |
Grid display |
Three types |
Time-lapse movie |
Shooting interval and number of shots settable, Required shooting time period, playback length, and remaining card capacity viewable |
Still photo shooting |
Not possible during movie shooting |
LCD Monitor |
|
Type |
TFT color, liquid-crystal monitor |
Monitor size and dots |
Wide 7.7cm (3.0in.) (3:2) with approx. 1.04 million dots |
Brightness adjustment |
Manual (7 levels) |
Electronic level |
Provided |
Interface languages |
25 |
Touch screen technology |
Capacitive sensing |
Feature guide / Help |
Displayable |
Playback |
|
Image display format |
Single-image display (without shooting information), Single-image display (with basic information), Single-Image display (Shooting information displayed: Detailed information, Lens / histogram, White balance, Picture Style 1, Picture Style 2, Color space / noise reduction, Lens aberration correction), Index display (4 / 9 / 36 / 100 images) |
Highlight alert |
Overexposed highlights blink |
AF point display |
Provided (may not be displayed depending on shooting conditions) |
Grid display |
Three types |
Zoom magnification |
Approx. 1.5 - 10x |
Image browsing methods |
Single image, jump by 10 or 100 images, by shooting date, by folder, by movies, by stills, by rating |
Image rotation |
Possible |
Image protection |
Possible |
Rating |
Provided |
Movie playback |
Enabled (LCD monitor, HDMI), built-in speaker |
Slide show |
All images, by date, by folder, by movies, by stills, by rating |
Background music |
Selectable for slide shows and movie playback |
Post-Processing of Images |
In-camera RAW image processing |
Brightness adjustment, White balance, Picture Style, Auto Lighting Optimizer, High ISO speed noise reduction, JPEG image-recording quality, Color space, Peripheral illumination correction, Distortion correction, Chromatic aberration correction |
Resize |
Provided |
Creative filters |
Grainy B/W, Soft focus, Fish-eye effect, Art bold effect, Water painting effect, Toy camera effect, Miniature effect |
Print Ordering |
|
DPOF |
Version 1.1 compliant |
Customization Features |
Custom Functions |
26 |
My Menu |
Up to 5 screens can be registered |
Custom shooting mode |
Register under Mode Dial’s C1 or C2 |
Copyright information |
Entry and appending possible |
Interface |
|
DIGITAL terminal |
Computer communication (Hi-Speed USB equivalent), GPS Receiver GP-E2, Connect Station CS100 connection |
HDMI mini OUT terminal |
Type C (Auto switching of resolution), CEC-compatible |
External microphone IN terminal |
3.5mm diameter stereo mini-jack |
Remote control terminal |
For Remote Switch RS-60E3 |
Wireless remote control |
Compatible with Remote Controller RC-6 |
Eye-Fi card |
Compatible |
Power |
|
Battery |
Battery Pack LP-E6N / LP-E6, quantity 1
* AC power usable with household power outlet accessories.
*With Battery Grip BG-E14 attached, AA / R6 batteries can be used. |
Battery information |
Remaining capacity, Shutter count, Recharge performance, and Battery registration possible |
Number of possible shots
(Based on CIPA testing standards, with 50% flash use) |
With viewfinder shooting: |
Approx. 960 shots at room temperature (23°C / 73°F),
approx. 860 shots at low temperatures (0°C / 32°F) |
With Live View shooting: |
Approx. 300 shots at room temperature (23°C / 73°F),
approx. 270 shots at low temperatures (0°C / 32°F) |
Movie shooting time |
Total approx. 1hr. 50 min. at room temperature (23°C / 73°F)
Total approx. 1hr. 40 min. at low temperatures (0°C / 32°F)
*With a fully-charged Battery Pack LP-E6N. |
Dimensions and Weight |
Dimensions (W x H x D) |
Approx. 139.0 x 105.2 x 78.5mm / 5.47 x 4.14 x 3.09in. |
Weight |
Approx. 730g / 25.75oz. (Based on CIPA Guidelines)
Approx. 650g / 22.93oz. (Body only) |
Operation Environment |
|
Working temperature range |
0°C - 40°C / 32°F - 104°F |
Working humidity |
85% or less |
Wireless Communications |
|
Standards compliance |
IEEE 802.11b/g/n |
Transmission method |
DS-SS modulation (IEEE 802.11b)
OFDM modulation (IEEE 802.11g/n) |
Transmission range |
Approx. 15m / 49.2ft.
* When connected to a smartphone
* With no obstructions between the transmitting and
receiving antennas and no radio interference |
Transmission frequency (central frequency) |
Frequency: |
2412 - 2462 MHz |
Channels: |
1 - 11 ch |
Connection method |
Camera access point mode, infrastructure*
* Wi-Fi Protected Setup supported |
Security |
Authentication method: Open system, Shared key, WPA/
WPA2-PSK
Encryption: WEP, TKIP, AES |
NFC connection |
For communication with smartphones or connection to Connect Station |
Wi-Fi Functions |
|
Connection to smartphones |
Images can be viewed, controlled, and received using a smartphone.
Remote control of the camera using a smartphone is possible.
Images can be sent to a smartphone.
|
Transfer images between cameras
|
Transferring one image, Transferring selected images, Transferring resized images |
Connect to Connect Station
|
Images can be sent to and saved on Connect Station. |
Remote operation using EOS Utility
|
Remote control functions and image viewing functions of EOS Utility can be used wirelessly. |
Print from Wi-Fi printers |
Images to be printed can be sent to a printer supporting Wi-Fi.
|
View images using a media player
|
Images can be viewed using a DLNA-compatible media player |
Send images to a Web service
|
Images in the camera or links to images can be sent to registered Web services |
Battery Pack LP-E6N |
|
Type |
Rechargeable lithium-ion battery |
Rated voltage |
7.2V DC |
Battery capacity |
1865mAh |
Working temperature range |
0°C - 40°C / 32°F - 104°F |
|
Working humidity |
85% or less |
Dimensions (W x H x D) |
Approx. 38.4 x 21.0 x 56.8mm / 1.5 x 0.8 x 2.2in. |
Weight |
Approx. 80g / 2.8oz. (excluding protective cover) |
Battery Charger LC-E6 |
|
Compatible battery |
Battery Pack LP-E6N / LP-E6 |
Recharging time |
Approx. 2hr. 30min. |
Rated input |
100 - 240V AC (50 / 60 Hz) |
Rated output |
8.4V DC / 1.2A |
Working temperaturerange |
5°C - 40°C / 41°F - 104°F |
Working humidity |
85% or less |
Dimensions (W x H x D) |
Approx. 69.0 x 33.0 x 93.0mm / 2.7 x 1.3 x 3.7in. |
Weight |
Approx. 115g / 4.1oz. |
Battery Charger LC-E6E |
|
Compatible battery |
Battery Pack LP-E6N / LP-E6 |
Power cord length |
Approx. 1m / 3.3ft. |
Recharging time |
Approx. 2hr. 30min. |
Rated input |
100 - 240V AC (50 / 60 Hz) |
Rated output |
8.4V DC / 1.2A |
Working temperature range |
5°C - 40°C / 41°F - 104°F< |
demen banget bro sama kamera ini. kamera DSLR yang menggunakan sepasang sistem fokus kamera yang kuat serta didukung dengan desain intuitif.
wah bagus banget nih kamera saya suka thanks plaza kamera karna udah dikirim tepat waktu harganya juga sesuai sukses terus plaza kamera
EOS 70D adalah SLR mid-range untuk fotografer antusias yang dari luar tampak seperti upgrade yang masuk akal.
kemampuan autofokusnya oke hasil foto juga sangat baik dengan penchayan yang cukup layar sentuhnya juga responsif.
I LOVE IT. pada awalnya aku agak ragu karena crop sensor. tapi ternyata saya suka banget dengan hasilnya. kemampuan face tracking dan auto fokusnya tak terkalahkan. aku sudah coba pakai berbagai macam lensa dan puas banget dengan hasilnya.
